RK-2000 RUKRA Elevator Phone

RK 2000 RUKRA Elevator Emergency PhonezijkantRK 1156 RUKRA Panel flush mount 220x145mm

Productinformation

• The RUKRA Elevator Phone is a product made in the Netherlands and it works very fine on every

   PSTN, GSM or VOIP phoneline without require any power or batteries.

• Maximum of 5 systems on 1 phoneline without require any power DURABLE AND MAINTENANCE FREE

• The RUKRA Elevator Phone is very compact and fits behind most cabine panels / COP

• Very thin, easy to install and with the many accessoires a complete alarmsystem for every Elevator in the world

• Webbased Callcenter to check all your Elevator Phones (also other brands)

5 modules op 1 lijn

• The Basic unit is powered from telephone line only
• The unit includes acoustic part (microphone and speaker)
• Programming is either remotely by phone or by PC or remotely from PC
• Indication lights: yellow, indication of dialling the number, green,indication confirm of call.
• Possible connect pushbutton with switch-on (NO) or switch-off (NC) contacts
• Possible connect two pushbuttons - one (in cabin) with Alarmfilter second without function Alarmfilter
• Input  for Alarmfilter to dial from button BTN2
• Special mode with Alarmfilter function (from move of cabine door)
• The time of each button activation is adjustable from 0,5 sec to 39 sec
• The possibility up to 5 Elevatorphones parallel from one telephone line
• The possibility up to 3 Elevatorphones paralel from „SwitchBoard“ for communication with machine room
• Automatic control of system functionality - Service call (from 1 to 59 days)
• Possible switched on acoustic tick to the conversation for speech recognition
• Adjustable parameters of tone dial, length of Flash and Pause
• Adjustable parametres of tones detector amd parametres of acoustical signalization
• Elektronical loudness settings ( without neccessity open the unit)
• The possibility to programm 6 numbers ( 16 digits – includes  *,#,Pause,Flash)
• Memory on two last dial telephone numbers
• Automatic audiotest (microphone and speaker). Switchtable by parameter.
• Automatic test of permanent activate button (BTN2)
• Possibility call to the machine room with SwitchBoard
• Posibility set  mute for service, technical and counter calls
Engineer arrived ENG

Specifications

BASEUNIT
• Conform NEN 81-28
• Automatic call through if no answer or busy line
• Alarmbuttons N.O. / N.C.
• Automatic alarmbutton(s) test
• Automatic audiotest (Speaker and microphone)
• “Silent” periodic test 1 to 30 days (NEN81-28
• Screw connectors for extra speaker, microphone and LED’s
• Double indication leds green and yellow
• Maximal 5 systems on 1 telephone line without extra powersupply
• Alarmfilter for alarmbutton in cabin
• Audio settings adjustable from distance
• Plug & Play with Phoenix connectors
• 3-Day line and systemtest NEN 81-28

POPULAIR OPTIONS

TECHNICALL
1 on 1 to replace with Faltcom, Dielro, Safeline, OTIS, KONE etc…
• NO POWER REQUIRED
• Automatic audiotest
• Automatic alarmbutton(s) test
• Lift monitoring module
• Web based call center
• Plug & Play connectors
• Surface and Flush mount carpanels
• Machineroom intercom
• More systems on 1 line (max. 5 without extra power)
• Programming local or from distance
• Compact size; 100*90*22mm
• Article number: RK-2000
Backside RK2000  Frontside RK2000 zijkant RK2000Dimensions RUKRA Elevator Emergency Phone

Programming

When you receive the RUKRA Elevator Phone we preprogrammed it for you with your settings (Phonenumbers, tests etc) but if you want to reprogram it by yourself there are 5 simular ways to do that:

Locally you can program with the Smart Programmer, with a Tablet / Laptop or from the intercom.

Remotely you can program with a regular (mobile) Telephone or a Computer with Black-Box modem.



Remotely with a Telephone:

1- Call the RUKRA Elevator Phone by (mobile) phone,
2- After the RUKRA elevator phone has picked up the line you are in the speak mode,
    Entering the programming menu:
3- Press key # 0000 (password is 0000) if the password is oke you will hear a three-tone beep to confirm,
    then you have 10 seconds to start programming.
(NOTE !!: After programming a function, you must wait until the RUKRA elevator phone beeps 1 second, then the programming is stored in the memory.
Download here the short programlist (70Kb)

Locally with a Telephone and the Smart Programmer:
1- Connect the Smart Programmer to the RUKRA Elevator Phone and pick up the handset of the Telephone,
2- Push The Alarmbutton, in, or on the Elevator for 5 seconds and wait till the the Elevator Phone starts calling,
    now you there is a speak connection between the Smart Programmer and the Elevator Phone,
    Entering the programming menu:
3- Press key # 0000 (password is 0000) if the password is oke you will hear a three-tone beep to confirm, then you have 10 seconds to start programming.
(NOTE !!: After programming a function, you must wait until the RUKRA elevator phone beeps 1 second, then the programming is stored in the memory.
Download here the short programlist (70Kb)

Locally from the machineroom Intercom:
1- Pick up the handset of the Telephone in the Machineroom,
2- You will be automaticly connected with the Elevator Phone in the Elevator,
    now you there is a speak connection between the intercom and the Elevator Phone,
    Entering the programming menu:
3- Press key # 0000 (password is 0000) if the password is oke you will hear a three-tone beep to confirm, then you have 10 seconds to start programming.
(NOTE !!: After programming a function, you must wait until the RUKRA elevator phone beeps 1 second, then the programming is stored in the memory.
Download here the short programlist (70Kb)

Locally with a computer and USB cable:
1- Dowload and install the program "RUKRA Elevator Setting",
2- Dowload and install the drivers for the USB cable,
3- Download the settings from the RUKRA Elevator phone and change the parameters that you want to reprogram.

OnLine Programmingservice:
Send an This email address is being protected from spambots. You need JavaScript enabled to view it. with the phonenumber of the line and the parameters that must be changed and we will do that for you

Software

RUKRA Elevator Setting Programm (ZIP 4.5Mb)


NOTE!! The drivers for the USB-Cable will not automatic be installed by Windows, read the
NOTE!! When you have problems with installing the software or drivers in Windows 8 read the
